Carbon Steel SCH80 ASME 90 Degree Elbow Fitting

Large Image : Carbon Steel SCH80 ASME 90 Degree Elbow Fitting

Product Details:

Place of Origin:	China
Brand Name:	Shengtian
Certification:	ISO9001
Model Number:	pipe fitting 001

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	1~100 US $6.7/ Piece >100 US $4.5/ Piece
Packaging Details:	In woonden cases or in pallet
Delivery Time:	15 DAYS
Payment Terms:	L/C, D/A, D/P, T/T, Western Union
Supply Ability:	20000000

Contact Now

Carbon Steel SCH80 ASME 90 Degree Elbow Fitting

Description

Radius:	LR SR	Standard:	DIN JIS BS EN ASTM ASME
Material:	Carbon Steel	Size:	1/2 Inch To 72 Inch
Degree:	30 45 60 90 180	Thickness:	Sch80
High Light:	ASME 90 Degree Elbow Fitting , SCH80 90 Degree Elbow Fitting , ASME 90 Degree Hose Elbow

Black Sch80 Seamless 45 90 Degree Lr Sr Forged Carbon Steel Pipe Fitting Elbow

Model NO.: carbon steel pipe fittings
Shape: Equal
Angle: 90 Degree
Material: Stainless Steel
Certification: ASME, ANSI, DIN, JIS, BS, GB, GS, KS, API
Size: up to 48"
Specification: GB12459/ASME/DIN/JIS
Connection: Welding
Head Code: Round
Wall Thickness: Sch80s
Technics: Cold Forming
Color: Black
Trademark: Shengtian
Origin: China

Carbon Steel SCH80 ASME 90 Degree Elbow Fitting 0

Pipe Size		Outside Diameter	90 Deg Elbows,	45 Deg Elbows,
(NPS)	DN	at Bevel	A	B


1	25	33.4	38	22
11⁄4	32	42.2	48	25
11⁄2	40	48.3	57	29
2	50	60.3	76	35
21⁄2	65	73	95	44
3	80	88.9	114	51
31⁄2	90	101.6	133	57
4	100	114.3	152	64
5	125	141.3	190	79
6	150	168.3	229	95
8	200	219.1	305	127
10	250	273	381	159
12	300	323.8	457	190
14	350	355.6	533	222
16	400	406.4	610	254
18	450	457	686	286
20	500	508	762	318
22	550	559	838	343
24	600	610	914	381
26	650	660	991	405
28	700	711	1067	438
30	750	762	1143	470
32	800	813	1219	502
34	850	864	1295	533
36	900	914	1372	565
38	950	965	1448	600
40	1000	1016	1524	632
42	1050	1067	1600	660
44	1100	1118	1676	695
46	1150	1168	1753	727
48	1200	1219	1829	759
