Product Details:
|
| Color: | Black | Technics: | Forged |
|---|---|---|---|
| Standards: | ASME B16.5 | Degree: | 30/45/90/180 |
| Surface Treatment: | Transparent Oil, Rust-proof Black Oil Or Hot Galvanized | Material: | Carbon Steel |
| High Light: | SCH60 45 Degree Pipe Fittings,A105 45 Degree Pipe Fittings,SCH60 45 Degree Pipe Elbow |
||
Manufacturer of ASTM A105 Carbon Steel Sch60 45 Degree Pipe Fittings Elbow
Exporter of 45 Deg Elbow, CS Long Pipe Fitting Elbow, Carbon Steel Elbows suppliers in China, Carbon Steel Long / Short Radius Elbow in China
Carbon Steel Pipe Fittings Elbow could be a most common sort of CS fitting utilized to connect pipe or tubing to permit a alter of direction, more often than not a 90° or 45° angle, though 22.5 Degree Elbow Carbon Steel is additionally utilized in a piping framework. All beat manufacturers utilize Carbon Steel Elbow Cold Shaping Machine in China . ASTM A105 Carbon Steel Elbows closes may be machined for butt welding, threaded, or socketed, so the elbows are comprise of butt weld, thread elbow, attachment elbow, and others .
Product Description
| Type | Pipe Fitting Elbow |
| Size | Seamless Elbow:1/2"~24" DN15~DN600 Welded Elbow: 1/2"~100" DN15~DN2500 |
| Wall thickness | sch10, sch20, sch30, std, sch40, sch60, xs, sch80, sch100, sch120, sch140, sch160, xxs, std,sch5s, sch20s, sch40s, sch80s |
| Standards | ANSI B16.9, ASME,DIN2506, JIS, BS,GOST |
| Material | Carbon steel: ASTM/ASME A234 WPB,WPC, ST37-2,ST54 Alloy steel: ASTM/ASME A234 WP9-WP12-WP11-WP22-WP5-WP91 Stainless steel: ASTM/ASME A403 WP 304-304L, WP 316-316L,WP 321,201 |
| Surface treatment | Transparent oil, rust-proof black oil or hot galvanized |
| Packing | wooden case, pallet or as customers' requirement |
| Applications | Petroleum, chemical, power, gas, metallurgy, shipbuilding, construction, etc |
| Min order | 10 piece |
| Delivery time | 7 after receipt of advanced payment |
| Certification | ASME, ISO9001:2000 |
| Delivery Term | FOB(30% down payment in advance, the balance before shipment) CIF or C&F(30% in advance , the balance against with the copy of B/L) |
Product picture
ASTM A105 Carbon Steel Sch60 45 Degree Pipe Fittings Elbow Manufacturer
Hebei shengtian pipe-fitting group Co., ltd. is highly acclaimed Carbon Steel Pipe Fittings Elbow manufacturers in China. We are shipping Carbon Steel 90 Degree Elbow, Carbon Steel 45 Degree Elbow and CS 180° elbows at discounted prices due to China is rich in steel resources and a significant source of high-quality Carbon Steel Short Radius Elbow at best price available in China.
We can also provide free sample of ASTM A105 Carbon Steel Sch60 45 Degree Pipe Fittings Elbow.So if you are looking for best price of Carbon Steel Reducing Elbow or Carbon Steel Flanged Elbow, Sch 80 Elbow Carbon Steel, Long Sweep Elbow Carbon Steel, 30 Degree Carbon Steel Elbow near you with shortest time delivery or free sample of Carbon Steel Buttweld Elbow. Call us or mail to sale@stpipefitting.cn for Latest & Updated price List of ASTM A105 Carbon Steel Pipe Fitting Elbow and Carbon Steel Pipe Fitting Elbow.
Dimensions of ASTM A105 Carbon Steel Sch60 45 Degree Pipe Fittings Elbow
| NPS | O.D. D |
90° Long Rad Center to End A |
45° Long Rad Center to End B |
90° 3D Center to End A |
45° 3D Center to End B |
| 1/2 | 21.3 | 38 | 16 | / | / |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1.1/4 | 42.2 | 48 | 25 | 95 | 39 |
| 1.1/2 | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2.1/2 | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3.1/2 | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 946 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
