Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded

Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded
Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded
Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded

Large Image :  Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded

Product Details:
Place of Origin: China
Brand Name: Shengtian
Certification: API5L ISO 9001:2008 TUV SGS BV etc
Model Number: Seamless steel pipe 006
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton
Price: 1-5 Tons US $526/ Ton;>5 Tons US $473/ Ton
Packaging Details: Bundles or in Bulk. Bundled Pipes with Two Slings
Delivery Time: 10-15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000 Tons/Month

Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded

Description
Production Capacity: 20000 Ton/Tons / Month Payment Terms: L/C, T/T
Joint Type: Welded Technique: Hot Rolled
Material: Carbon Steel Transport Package: As The Contract
Surface Treatment: Black Section Shape: Round
Port: China
High Light:

sch40 seamless carbon steel pipe

,

a53 seamless carbon steel pipe

,

a106 cs seamless pipe

Sch40 A53 A106 API 5L Welded Carbon Seamless Steel Pipe


Product Description



Product Name Sch40 A53 A106 API 5L Welded Carbon Seamless Steel Pipe
Size OD 1/2"-48"
Thickness 7.92mm-50.8mm
Length SRL,DRL,5.8M,11.8M
Steel Material ASTM A53/A106,API 5L,EN10216,DN1626
Steel Grade Grade A,Grade B,Grade C,X42,X52.S235JRH,S355,P265 ect.
Process Hot rolled/hot expansion/cold drawn/cold rolled
Usage High temperature service
Surface Bared Black Painting, Galvanized,Coating
Proctor Plastic cap
Package Bundles, Bulk
Inspection With Hydraulic Testing, Ultrasonic testing or X-ray Test
Certificate ISO9001;2000
Date of Delivery Less Than 15/20/25/30/40/50/60 Days According To The Quantity
Payment: L/C or T/T
Port of Shipment China



HIGH QUALITY SEAMLESS PSL1 AND PSL2 STEEL PIPES
Standard: API 5L/ ASME B36.1M
Steel Grade:A53 Gr/A106 GR.A GR.B
Size and OD: 1/8"-24"(10.3mm-610mm)



Standard: API5L PSL 1 & PSL 2
Steel Grade:GrB to X70
Size and OD: 1/2"-152"(21.3mm-3800mm)
Wall Thickness: SCH10... STD,SCH40,SCH80...SCH160,XS,XXS.

Standard Steel Grade Chemical Components Machanical Property
C Mn Cr Mo P S Ni Cu Tensile Strength (Mpa) Yield Strength(Mpa)
API Spec 5L PLS1 B ≤0.28 ≤1.20 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥415 ≥245
X42 ≤0.28 ≤1.30 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥415 ≥290
X46 ≤0.28 ≤1.40 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥435 ≥320
X52 ≤0.28 ≤1.40 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥460 ≥360
X56 ≤0.28 ≤1.40 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥490 ≥390
X60 ≤0.28 ≤1.40 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥520 ≥415
X65 ≤0.28 ≤1.40 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥535 ≥450
X70 ≤0.28 ≤1.40 ≤0.50 ≤0.15 ≤0.030 ≤0.030 ≤0.50 ≤0.50 ≥570 ≥485

Standard Steel Grade Chemical Components Machanical Property
C Mn Cr Mo P S Ni Cu Tensile Strength (Mpa) Yield Strength(Mpa)
API Spec 5L PLS2 BN ≤0.24 ≤1.20 ≤0.30 ≤0.15 0.025 0.015 ≤0.30 ≤0.50 415-655 245-450
X42N ≤0.24 ≤1.20 ≤0.30 ≤0.15 0.025 0.015 ≤0.30 ≤0.50 415-655 290-495
X46N ≤0.24 ≤1.40 ≤0.30 ≤0.15 0.025 0.015 ≤0.30 ≤0.50 435-655 320-525
X52N ≤0.24 ≤1.40 ≤0.30 ≤0.15 0.025 0.015 ≤0.30 ≤0.50 460-760 360-530
X56N ≤0.24 ≤1.40 ≤0.30 ≤0.15 0.025 0.015 ≤0.30 ≤0.50 490-760 390-545
X60N ≤0.24 ≤1.40 ≤0.50 ≤0.50 0.025 0.015 ≤0.50 ≤0.50 520-760 415-565
X65Q ≤0.18 ≤1.70 ≤0.50 ≤0.50 0.025 0.015 ≤0.50 ≤0.50 535-760 450-600
X70Q ≤0.18 ≤1.80 ≤0.50 ≤0.50 0.025 0.015 ≤0.50 ≤0.50 570-760 485-635



Company introduction



 Established in 1989, Hebei Shengtian Pipe-Fitting Group Co., Ltd. located in Mengcun County Hebei Province China, covering a land area of 100,000 square meters, with a workshop of 25,000 square meters and registered capital of 110 million RMB. Our company has a strong staff team. There are over 360 employees, including over 30 professionals and technicians.

  We are capable of manufacturing various pipe fittings. Our main products scope: steel elbow, tees, bends, reducers, caps, forged flanges and sockets. We have been in this line for over 20 years. Our products are exported to many countries and regions, such as Southeast Asia, the Middle East, Europe and America etc. Our pipes and pipe fittings enjoy a good reputation in domestic and foreign markets. Every year, hundreds of foreign visitors and innumerable domestic visitors come to our company for business cooperation.

  We have first-class inspection devices, perfect detecting means and well-trained specialists. And we stick to ISO9000:2000 quality system and efficiently control procedure in production. We have confidence that we can supply the best quality products. We would like to take responsibility for any quality uncertainty. Even so, our price is competitive. Besides, we can provide the best service to you.

  In order to avoid the policy of the anti-dumping duties imposed on pipe & fittings from the Europe, United States and other countries, We can re-export through other countries like Malaysia, etc, to circumvent the anti-dumping duties, which could make you to win more competitive price.



Product Process




Sch40 A53 A106 API 5L Seamless and Welded Carbon Steel Pipe




If you have any need please don't hesitation to contact to us ,we will offer warm-hearterd
service to you!


Sch40 A53 A106 API 5L Seamless and Welded Carbon Steel Pipe





Product Pictures





Sch40 A53 A106 Api 5l Seamless Carbon Steel Pipe Welded 2
