Black DN25 Cs Concentric Reducer Forged For Industry

Black DN25 Cs Concentric Reducer Forged For Industry
Black DN25 Cs Concentric Reducer Forged For Industry

Large Image :  Black DN25 Cs Concentric Reducer Forged For Industry

Product Details:
Place of Origin: China
Brand Name: ST
Certification: SGS/ISO9000/EN10204 3.1B/TUV
Model Number: pipe fitting 061
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: 1-100 pieces US $0.53/ Piece;>100 pieces US $0.41/ Piece
Packaging Details: in Wooden Cases or Customers Requirements
Delivery Time: 7-15 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80000 pieces/month

Black DN25 Cs Concentric Reducer Forged For Industry

Description
Material: Carbon Steel Color: Black
Technics: Forged Name: Butt Weld Steel Reducer
Type: Concentric Application: Industry,Pharmaceutical
Origin: China Transport Package: Plywood Boxes Or Pallets
High Light:

DN25 cs concentric reducer

,

Industry Forged cs concentric reducer

,

DN25 carbon steel concentric reducer

DN25 Carbon Steel Seamless ASTM Pipe Fittings Butt Weld Concentric Reducer





Product Description





Product specification:  3/4 "X1/2" --- 48 "X 40" [DN 20 X 15 --- 1200 X 1000]
Wall thickness dimension:  Sch 5s --160
Executive standards:  GB/T12459-2005, ANSI, JIS, BS, DIN, UNI, etc
Product material:  carbon steel, stainless steel,
Packaging method:  fumigation free wooden cases and pallets can be specially packaged according to customer requirements.
Product Quality:    ISO9001:2008 quality management system certification, ISO14001 environmental management system certification, OHSAS18001 occupational health and safety management system, pressure pipeline special equipment manufacturing license, member of the first level supply network of State Power Corporation and China National Petroleum Corporation
Product use: Oil and gas pipeline project, natural gas pipeline project, chemical plant, power plant, shipyard, pharmacy, dairy, beer, beverage, water conservancy, etc
Material Carbon steel: 10 #, 20 #, A3, Q235A, 20G, 16Mn, ASTM A234, ASTM A105
Stainless steel: ASTMA403, 1Cr18Ni9Ti, 0Cr18Ni9, 00Cr19Ni10, 00Cr17Ni14Mo2, 304, 304L, 316, 316L, etc





Reducer is a kind of pipe fitting used for pipe diameter. The commonly used forming process is reducing, expanding or reducing plus expanding, and stamping can also be used for reducing pipes of certain specifications.
A. Reducing/expanding forming
The reducing forming process of the reducer is to put the tube blank with the same diameter as the big end of the reducer into the forming die. By pressing along the axial direction of the tube blank, the metal moves along the die cavity and shrinks to form. According to the size of reducer, it can be divided into one press forming or multiple press forming.
B. Stamping forming
In addition to using steel pipes as raw materials to produce reducers, the reducers of some specifications can also be produced by using the steel plate stamping process. The shape of the die used for drawing is designed according to the size of the inner surface of the reducer, and the blanking steel plate is punched and stretched with the die.
Before bonding the reducer, the socket side and the outside of the socket shall be wiped with a dry cloth. When there is oil stain on the surface, it must be wiped with acetone. The following points should be noted:
1. Control caliber: DIN standard (DN10-DN150), 3A/IDF standard (1/2 "- 6"), ISO standard( Ф 12.7- Ф 152.4);
2. International industrial standards: DIN, ISO, SMS, 3A, IDF, etc;
3. Product material: stainless steel 304, 316, 316L;
4. Quality and application: The reducer is treated with high-grade polishing equipment inside and outside to meet the surface precision requirements; This product is suitable for dairy, food, beer, beverage, pharmacy, cosmetics and other industrial fields;
5. External processing: non-standard products can be processed with drawings and samples according to user requirements;
6. Connection mode: clamp (quick installation) type, welding type, thread (union) type.
Note that the reducer is also suitable for pipe diameter reduction in the environmental protection and dust removal industry, which is generally made of rolled steel plates, cut and welded, with different pipe diameters and materials
Generally, they are hot-rolled coils, which are applied very well and can save costs.
